Product Description
Key Points:
| MRC Rated Capacity | 2200 Lb / 1000 Kg |
| Voltage | 1 Phase 220~240V 50/60Hz |
| Speed (f/m) / min | 13ft/min / 4m/min |
| Load Chain Type | G80 |
| Control Included | Wireless Telecontrol |
Key Features:
- H4/M5-M6/2m-3m/Class C-Class D duty cycle classification applies to lifting equipment used in high-volume heavy load handling, such as steel handling and manufacturing operations, or in lighter-load automatic cycles like heat treatment, operating up to 30 minutes per hour with a maximum of 300 starts, a 50% operational time factor (K = 0.65), and a life expectancy of 10,000 hours.
- Heavy Duty Control System Powered by a powerful Motor with IP54IEC Motor Protection
- Standards Compliance and or Certifications Meets US and EU Standards ASME HST-1, ASME B30.16, EN14492-2, EN60204-32 , ,
Technical Specifications:
| MRC Rated Capacity | 2200 Lb / 1000 Kg | Chain Length (ft) | 25 m |
| Number of Speeds | 1 Speed | Control Range | 300 ft Wireless |
| Duty Class | H4/M5/2m/Class D | FCC Cert ID | OFNF21 |
| Standard Lifting Height | 80 ft / 24 m | Total Power Watts | 0.9 kW |
| Voltage | 1 Phase 220~240V 50/60Hz | Noise Level | 75 dB |
| Speed (f/m) / min | 13ft/min / 4m/min | Humidity | 80% |
| Control Voltage | 36V | IEC Motor Protection | IP54 |
| Control Included | Wireless Telecontrol | Standards Compliance | Meets US and EU Standards ASME HST-1, ASME B30.16, EN14492-2, EN60204-32 |
| Load Chain Type | G80 | Warranty | 3 Year |
| Load Chain Size | 7x20 mm | Emergency Stop | Yes |
| Rig Chain Falls / Lines | 1 |
