Product Description
Technical Specifications:
| Number of Speeds | 1 Speed | Transmission / Reducer Type | 3-Stage Planetary |
| Voltage | Battery Power 12 VDC | Free Spooling Clutch Type | Sliding Ring Gear |
| Speed (f/m) / min | 3~25 ft / 0.9~8 m | Gear Ratio | 250:1 |
| Control Voltage | 12 V | Electric Control Box | Reverse Solenoid Control Box |
| Control Included | Wireless and Wired | Accessories | Control and Installation Hardware |
| Motor Model | DC Series Wound Motor | IEC Motor Protection | IP67 |
| Motor AMP | 334 AMP | Warranty | 3 Year |
| Drum Brake | Automatic | Fairlead | Included |
| Wire Rope Included | Steel ø3/8 in x 85 ft | ø9.5 mm x 26 m | Number of Layers | 4 |
| 1st Layer MRC Capacity | 13500 lbs | Drum DL Length | 224 mm |
| FCC Cert ID | 2ASYP-DW12K | Drum BD Barrel Diameter | 64 mm |
