Product Description
Key Points:
| MRC Rated Capacity | 440 lb @ 2 lines | 220 lb @ 1 line |
| Voltage | 1 Phase 110~120V 60Hz |
| Number of Speeds | 1 Speed |
| Duty Class | H1/M2/1Cm/Class A |
| Control Included | Wireless F21 Remote Control |
Key Features:
- H1/M2/1Cm/- duty cycle classification describes lifting equipment used infrequently for installing and maintaining heavy equipment, operating up to 7.5 minutes per hour with a maximum of 75 starts, a 12.5% operational time factor (K = 0.65), and a life expectancy of 1,250 hours.
- Standards Compliance and or Certifications ASME HST-4 , ASME B30.16 , B30.17 , EN14492-2 , EN60204-32 , Intertek 4006091 , CAN/CSA C22.2 , EN14492-2 , EN60204-32 ,
Technical Specifications:
| MRC Rated Capacity | 440 lb @ 2 lines | 220 lb @ 1 line | Wire Rope Included | ø1/8 in | ø3 mm |
| Number of Speeds | 1 Speed | FCC Cert ID | OFNF21 |
| Duty Class | H1/M2/1Cm/Class A | Noise Level | 71 dB |
| Standard Lifting Height | 40ft single line / 20ft double line (12m / 6m) | Trolley Speed /min | 52 ft / 16 m |
| Voltage | 1 Phase 110~120V 60Hz | Trolley Number of Speeds | 1 |
| Speed (f/m) / min | 33 ft/10m @1line | 16ft/5m @2line | I-Beam Width Range | 2-4.5 in / 50-114 mm (Extension Kit Available) |
| Control Voltage | 110 V | Minimum Turn Radius | 2.62 ft / .8 m |
| Control Included | Wireless F21 Remote Control | Humidity | <85% |
| Motor Model | Squirrel Cage Induction Motor | Temperature | -4°~104° F / -20°~40° C |
| Motor Power | 460 W | IEC Motor Protection | IP40 |
| Motor AMP | 4.1 AMP | Standards Compliance | ASME HST-4 , ASME B30.16 , B30.17 , EN14492-2 , EN60204-32 |
| Motor Insulation Grade | B | Warranty | 1 Year |
| Motor Brake | YES |
