Product Description
The DW618PK 2-1/4 HP EVS Fixed Base / Plunge Router Combo Kit w/ Soft Start has a powerful motor for routing through tough hardwood at the user's desired speed. Features precise depth adjustments and fast, easy motor pack removal for bit and base changes. The plunge base integral dust collection provides superior bit visibility.
FEATURES & SPECS
FEATURES
- 2-1/4 HP (maximum motor HP), 12.0 amp electronic variable speed motor provides the power to rout smoothly through the toughest hardwoods
- Electronic variable speed with full feedback control for constant speed under load from 8,000-24,000 rpm and soft start to reduce start-up torque for enhanced control
- Micro-fine, depth-adjustment ring provides precise depth adjustments in 1/64" increments and adjusts vertically for a constant switch/cordset location
- Adjustable, tool-free, steel motor cam lock makes depth adjustment and base changes quick and solid-locking
- Integral, through-the-column dust collection collects 95% of the dust and provides superior bit visibility
- Quick-release motor latches for fast and easy motor pack removal for bit and base changes
- Detachable cordset offers cordset serviceability and removes the need for a "shorty" cord motor pack
- Precision-machined brass bushings and case-hardened steel guide rods provide a smooth and accurate plunge stroke
- Spindle lock button allows for single-wrench bit changes
- Clear, LEXAN sub-base provides enhanced base durability, bit visibility, and accepts standard template guide bushings
- Rubber overmolded handles and low center of gravity design provide best-in-class comfort, balance, and control
- Dust-Sealed Switch protects against dust ingestion for longer switch life
- Heavy-duty, precision-machined, die-cast aluminum base and motor housing for durability and low tool weight
- Nickel-plated motor housing for a smooth, long-lasting depth adjustment
- Right or left switch and cordset location provides the ability to have the switch in your right or left hand
- Flat top for easy bit and depth changes
- Self-releasing, long, eight slotted collets for better bit retention and elimination of frozen bits
- Five-position, adjustable turret stop assists in stepped or repeated plunge cuts
- Easy to reach plunge lever and switch for superior control while routing
- Micro-fine, depth-adjustment on plunge base 5/128" per turn for precise routing in veneer and inlays
SPECIFICATIONS
- AMPS 12.0 AMPS
- BASE DIMENSION 6 IN
- COLLET DIAMETER 1/2", 1/4 IN
- DEPTH STOP MICRO-FINE DEPTH ADJUSTMENT RING
- NO LOAD SPEED 8,000-24,000 RPM
- PEAK HORSEPOWER 2 1/4 HP
- PLUNGE STROKE 2-1/2 IN
- POWER TOOL TYPE CORDED
- ROUTER BASE COMBO KIT
- ROUTER TYPE MIDSIZE ROUTER
- SPINDLE LOCK YES
- TOOL WEIGHT 10.1 LBS
INCLUDES
- DW618M motor pack
- DW6184 fixed base
- DW6182 plunge base
- 1/4" and 1/2" collets
- Wrench
- Large hole sub base
- Vacuum adapter
- Kit Box
