Product Description
Corded fixed base router kit with 1-3/4 HP motor, 11 Amp power, micro-fine depth adjustment, quick-release motor latches, and durable die-cast aluminum housing. Includes kit box and accessories.
Overview
The Dewalt DW616K Fixed Base Router Kit delivers smooth routing performance through hardwoods with its powerful 11 Amp, 1-3/4 HP motor. Designed for precision, it features a micro-fine depth adjustment ring for 1/64" increments, quick-release motor latches for easy bit and base changes, and a detachable cordset for serviceability. The clear Lexan sub-base enhances visibility and accepts standard template guide bushings, while rubber overmolded handles and a low center of gravity provide superior comfort and control. This kit includes a motor pack, fixed base, collets, concentricity gauge, wrenches, and a durable kit box.
Key Features
-
1-3/4 HP, 11 Amp motor for hardwood routing
-
Micro-fine depth adjustment ring (1/64" increments)
-
Tool-free steel motor cam lock for quick adjustments
-
Quick-release motor latches for easy bit/base changes
-
Detachable cordset for serviceability
-
Sub-base concentricity gauge for accuracy
-
Clear Lexan sub-base for durability and visibility
-
Rubber overmolded handles for comfort
-
Dust-sealed switch for longer life
-
Die-cast aluminum base and housing for durability
-
Nickel-plated motor housing for smooth adjustments
-
Kit includes DW616M motor pack, DW6184 fixed base, collets, gauge, wrenches, and kit box
Technical Specs
-
Model Number: DW616K
-
Motor Power: 11 Amps
-
Peak Horsepower: 1-3/4 HP
-
No Load Speed: 24,500 RPM
-
Base Dimension: 6"
-
Collet Diameter: 1/4", 1/2"
-
Depth Stop: Micro-fine adjustment ring
-
Tool Weight: 7.1 lbs
-
Router Type: Midsize, Fixed Base
-
Power Tool Type: Corded Router Kit
Includes
-
DW616M Motor Pack
-
DW6184 Fixed Base
-
1/4" and 1/2" Collets
-
Sub-base Concentricity Gauge
-
(2) Wrenches
-
Kit Box
End-of-Page Summary
Dewalt DW616K Fixed Base Router Kit with 1-3/4 HP motor, micro-fine depth adjustment, quick-release latches, and durable die-cast aluminum housing. Complete kit includes motor pack, base, collets, gauge, wrenches, and kit box.
