Product Description
The ZONEPACK GFK-160 is a compact, digital-control liquid filling machine designed for small production runs, laboratories, cosmetics, beverages, and light industrial applications. It uses a self-priming magnetic gear pump to deliver accurate, repeatable fills with low-viscosity liquids. The stainless-steel housing, LCD control panel, and automatic counting system make it a reliable and easy-to-operate solution for bottling water, wine, vinegar, soy sauce, skincare liquids, perfumes, and similar products.
Key Features
Digital Control System
-
Microcomputer-based control for precise volume adjustment
-
Automatic counting function for batch accuracy
-
LCD display with six programmable parameter sets
Self-Priming Pump
-
Draws liquid directly from your container
-
Supports up to 2 m suction distance
-
Handles water-thin liquids without particles
Adjustable Filling Range
-
5 ml to 3500 ml per cycle
-
Max flow rate: 3.2 L/min
-
Repeat error: < 0.5%
Stainless Steel Construction
-
Easy to clean
-
Corrosion-resistant
-
Meets general GMP handling requirements
Upgraded Compact Design
-
Reduced size and weight for easier storage and portability
-
Same performance as the previous GFK-160 model
Specifications
-
Power: 30W
-
Filling Range: 5–3500 ml
-
Max Flow Rate: 3.2 L/min
-
Max Suction Distance: 2 m
-
Nozzle Diameter: 8 mm
-
Product Dimensions: 15.75" × 15.35" × 7.09"
-
Item Weight: 6.04 lb
-
Package Size: 400 × 380 × 200 mm
-
Model: GFK-160
-
Country of Origin: China
Applications
Suitable for:
-
Water, beverages, wine, vinegar
-
Soy sauce and thin food liquids
-
Perfume, skincare liquids, essential-oil blends
-
Light chemical solutions
-
Laboratory and small-batch production
Not suitable for:
-
Highly viscous liquids
-
Liquids thicker than edible oil
-
Corrosive or strong acid/alkali solutions
-
Liquids containing particles
Included Features
-
Stainless-steel housing
-
LCD digital control panel
-
Self-suction pump
-
Anti-drip nozzle design
-
Saveable parameter presets
-
Air-purge function for priming
Common Accessories (Optional)
-
4 mm nozzle for small bottles
-
10 mm nozzle for higher flow
-
2 m replacement tubing
-
Inline filter
Ideal For
-
Small businesses
-
Home production
-
Cosmetics and skincare labs
-
Beverage sampling lines
-
Hobby bottling
-
Light industrial filling task
