Overview

The UEi 521KIT Gas Furnace Install Kit is a complete professional solution designed to help technicians properly install, verify, and maintain gas furnace systems. The kit includes industry-recommended testing instruments that support manufacturer installation requirements and warranty documentation procedures.

The EPC True-RMS Wireless Clamp Meter verifies voltage and grounding performance. The EM720SPKIT Differential Manometer measures external static pressure and airflow performance. The PDT655 Differential Pocket Thermometer measures supply and return duct temperatures for temperature rise calculations. The CD100A Combustible Gas Leak Detector helps verify gas system safety, while the COA2 Carbon Monoxide Analyzer monitors dangerous carbon monoxide levels in residential and commercial environments.

All components are conveniently organized in the included AC550 Heavy Duty Tool Backpack.

Key Features

• Complete gas furnace installation and service kit
• EPC True-RMS wireless clamp meter included
• EM720SPKIT differential manometer and static pressure kit
• PDT655 differential pocket thermometer
• CD100A combustible gas leak detector
• COA2 carbon monoxide analyzer
• Supports temperature rise and airflow diagnostics
• Measures electrical performance and grounding
• Detects combustible gas leaks
• Monitors carbon monoxide concentrations
• Bluetooth app integration for data logging
• Professional heavy-duty tool backpack included

Use Cases

• Gas furnace installation
• Furnace commissioning
• Electrical diagnostics
• Static pressure testing
• Temperature rise verification
• Gas leak detection
• Carbon monoxide monitoring
• HVAC maintenance and troubleshooting
• Warranty documentation and startup verification

Compatibility

Designed for:

• Residential Gas Furnaces
• Commercial Gas Heating Systems
• HVAC Heating Equipment
• Forced-Air Heating Systems
• Natural Gas Systems
• Propane Furnace Systems

Benefits

• Supports manufacturer-recommended installation practices
• Helps document startup readings for warranty compliance
• Improves system safety through leak and CO monitoring
• Combines multiple HVAC diagnostic tools into one kit
• Simplifies field testing and commissioning
• Enhances installation accuracy and technician efficiency
• Provides professional documentation capabilities through mobile app connectivity

FAQ

Q: What tools are included in the 521KIT?

A: The kit includes the EPC Clamp Meter, EM720SPKIT Differential Manometer, PDT655 Differential Thermometer, CD100A Gas Leak Detector, COA2 Carbon Monoxide Analyzer, and AC550 Heavy Duty Tool Backpack.

Q: Can this kit detect gas leaks?

A: Yes. The CD100A combustible gas leak detector helps technicians identify gas leaks and verify system safety.

Q: Does the kit monitor carbon monoxide levels?

A: Yes. The included COA2 carbon monoxide analyzer measures CO concentrations from 0 to 999 ppm.

Q: Can technicians document readings during installation?

A: Yes. The kit supports recording and data logging through a compatible mobile application.

Q: Is this kit suitable for furnace commissioning?

A: Yes. The included instruments support electrical, airflow, temperature, gas leak, and CO testing required during installation and commissioning.

Technical Specs

General

• Part Number: 521KIT
• Product Type: Gas Furnace Install Kit
• Mobile App Compatible: Yes (Android™ and iOS®)
• Display Count: 6000
• Dual Display: Yes
• Display Backlight: Yes
• Hold Function: Yes
• Min/Max Function: Yes
• Auto Power Off: Yes
• Digital Display: Yes
• Recording/Data Logging: In App

Electrical Measurement

• True RMS: Yes
• AC Voltage: 750VAC
• DC Voltage: 1000V DC
• AC Current: 600A AC
• AC Millivolts: 600mV
• DC Millivolts: 600mV
• Frequency: 99.99kHz
• Duty Cycle: Yes
• Resistance: 60 MΩ
• Capacitance: 6000µF
• Continuity: Yes
• Diode Test: Yes
• Low Z: Yes
• NCV Detection: Yes
• Inrush Current Measurement: Yes

Airflow & Pressure

• Differential Pressure Range: ±60 InH₂O
• Dual Pressure Input: Yes
• Zero Function: Yes
• Selectable Units: Yes

Temperature

• Temperature Range: -328°F to 2462°F
• Temperature Differential: Yes
• K-Type Input: Yes
• Folding Temperature Probe: Yes

Gas & Safety Measurements

• Carbon Monoxide Range: 0 to 999 ppm
• Detects: Combustible Gas
• Detection Sensitivity: Less Than 50 ppm Methane
• Digital Numeric Leak Indicator: Yes

Additional Features

• Protective Boot/Overmolding: Yes
• Magnetic Mount: Yes
• High Resolution Accuracy: Yes
• Average Function: In App

Safety & Certifications

• IP42 Rated
• cETLus Listed
• IEC 61010-1:2012
• CE Compliant
• RoHS Compliant
• FCC Compliant
• CAT IV 300V / CAT III 600V

Included Components

• EPC True-RMS Wireless Clamp Meter
• EM720SPKIT Differential Manometer
• CD100A Combustible Gas Leak Detector
• COA2 Carbon Monoxide Analyzer
• PDT655 Differential Pocket Thermometer
• AC550 Heavy Duty Tool Backpack

Warranty

• Various Manufacturer Warranties Depending on Included Components

Shipping Information

• Ships securely packed in the included professional-grade tool backpack.
• Designed for HVAC installation, commissioning, and safety verification applications.

Who This Is For

• Gas Furnace Installers
• HVAC Service Technicians
• Heating Contractors
• Safety Inspection Professionals
• Building Maintenance Teams
• Mechanical Service Contractors

End-of-Page Summary

The UEi 521KIT Gas Furnace Install Kit combines electrical diagnostics, airflow testing, differential temperature measurement, combustible gas leak detection, and carbon monoxide monitoring into one complete professional package. Designed for installation verification, commissioning, maintenance, and safety testing, this kit helps technicians ensure proper operation while meeting manufacturer warranty requirements.
